Automation of Hygienic Design in Turnkey Facility Installation: Ensuring Flawless Surface Finishes with Robotic Welding and CNC Manufacturing

In the food, pharmaceutical, biotechnology, and chemical industries, hygienic design is now a necessity rather than a choice. Hygienic design, which has a direct impact on product quality, safety, and operational efficiency, is a goal difficult to fully achieve with traditional manufacturing methods. This article examines how robotic welding, CNC (Computer Numerical Control) manufacturing, and automation technologies are combined to ensure the consistent and flawless application of hygienic design principles in turnkey projects. It will address in-depth technical details on how to build a process free from human error, with high repeatability, and 100% compliant with hygienic design rules.

Challenges of Hygienic Design and the Imperative of Automation

Hygienic design is the design of equipment or a facility to maximize cleanability and minimize the risk of harboring bacteria, biofilms, and contaminants. The main challenges encountered in traditional manufacturing are:

• The Nature of Manual Welding: Manual welding is dependent on operator skill. Porosity, cracks, concave/convex welds, and insufficient penetration are inevitable. These defects create ideal harborage areas for microorganisms.

• Surface Roughness (Ra Value): Standard manufacturing methods cannot consistently achieve the required ≤ 0.8 µm Ra (sometimes ≤ 0.4 µm) value for food contact surfaces. Rough surfaces resist cleaning chemicals and mechanical cleaning.

• Dead Spots and Geometric Constraints: Sharp corners, inaccessible areas, and low-quality assemblies reduce the effectiveness of cleaning procedures.

• Human Error and Inconsistency: Mistakes during assembly, incorrect bolt tightening torques, misplaced gaskets, and similar factors compromise hygienic integrity.

These challenges are unacceptable in projects adopting a “turnkey” philosophy. The client expects the entire process, from design to commissioning, to be reliable and standardized. It is at this point that automation becomes not a solution, but a necessity.

Digital Twin and Preparation for Automation in the Design Phase
The automation process begins in the digital environment, before manufacturing.

• CAD (Computer-Aided Design): Hygienic design rules (3-A, EHEDG, ASME BPE) are integrated into CAD software libraries. The designer cannot create rule violations like sharp corners or unnecessary threading, or the software instantly warns them.

• CAE (Computer-Aided Engineering): Finite Element Analysis (FEA) simulates welding stresses and thermal distribution, while Computational Fluid Dynamics (CFD) simulates cleaning profiles. This optimizes the welding parameters that the automation will produce.

• Digital Twin: A virtual copy of the entire system is created. This model is used for robot programming, collision checks, and assembly simulations. The robot’s welding angle, speed, and power, as well as the CNC machine’s tool path, are determined here.

Robotic Welding: Eliminating Microscopic Defects
Robotic welding has revolutionized hygienic design. Particularly, Argon or Tungsten Inert Gas (TIG/WIG) welding robots provide weld consistency unattainable by the human hand.

• Repeatability and Precision: 6-axis industrial robots can repeat the same weld path infinitely with precision below ±0.1 mm. This means all welds are geometrically and metallurgically identical.

• Parameter Control: All parameters such as current, voltage, welding speed, inert gas flow, and cooling time are digitally controlled and recorded. This data creates an “identity card” for each weld seam, ensuring full traceability.

• Flawless Weld Geometry: The robot produces smooth, slightly convex, and pore-free welds. Welds are made with a smooth transition to the base material, preventing hard-to-clean crevices.

• Automatic Quality Control (AQC): Integrated laser scanners verify part position before welding. Thermal cameras monitor heat distribution during welding, detecting potential faults in real-time.

CNC Manufacturing and Machining: Surface Quality at the Nanometric Level
CNC machines are indispensable for achieving the geometric perfection and surface quality required by hygienic design.

• 5-Axis Continuous Machining: This technology completely eliminates sharp internal corners. By accessing every point of the part continuously and at an optimal angle, equal and low roughness is achieved on all surfaces. For example, all interior surfaces of a tank can be machined in a single setup while preserving radiused corners.

• Surface Roughness Control: With proper cutting tool selection, cutting speed, feed rate, and cooling strategies, surfaces below 0.4 µm Ra are consistently obtained. This is a “micro-level” smoothness that largely prevents bacterial adhesion.

• Material Integrity: CNC machining minimizes scratches, work hardening, or micro-crack formation on the surface. When combined with final processes like electropolishing, the surface not only becomes smooth but is also coated with a passive chromium oxide layer, increasing corrosion resistance.

Robotic Assembly and Final Inspection: Minimizing Human Intervention
The assembly stage after welding and machining also benefits from automation.

• Coordinate Measuring Machines (CMM): Every completed part is 100% inspected by a CNC-programmed CMM. Measurement data is compared with the CAD model, and no out-of-tolerance part proceeds to the assembly line.

• Automated Guided Vehicles (AGVs) and Robotic Arms: Parts are transported to assembly stations by AGVs. Robotic arms place gaskets in the correct position and with the correct torque, and tighten flange connections without allowing for human error.

• Vision Systems and Artificial Intelligence: Camera systems detect missing gaskets, misalignments, or surface defects. Machine learning algorithms improve the fault detection accuracy of these systems over time.

Integration into the Turnkey Process and Benefits
All these automated processes provide the following concrete benefits to turnkey project management:

• 100% Design Compliance: The entire process, from digital twin to physical product, is executed in strict adherence to hygienic design rules.

• Predictability and On-Time Delivery: With human error and inconsistency minimized, project timelines become much more reliable.

• Superior Quality and Traceability: Every single part and weld seam is digitally archived along with its production data. This means a complete quality assurance file is presented to the client.

• Long-Term Operational Cost Optimization: Automated hygienic design shortens cleaning times, reduces chemical and water consumption, extends equipment lifespan, and lowers product loss risk.

In critical sectors like food and pharmaceuticals, hygiene is not a cost item but an investment. In turnkey projects, the guarantee of this investment can now be provided not by traditional methods, but by high-tech automation processes. Robotic welding and CNC manufacturing transcend the limits of the human hand, translating hygienic design principles into the physical world with near-perfection. This approach builds not only cleanable equipment but also the cornerstone of safer products, more efficient facilities, and ultimately, a healthier society. The future lies in these “flawless” processes where digital design, robotic manufacturing, and smart data management are intertwined.
